Cimco Qeshm Company has started it`s activity from 1995 and concentrated on special brands with high quality products under European certifications.

We have a guildline which is: working on high quality products with special services for dear consumers during all these years.[Read More]

Ball Valves

Ball Valves

  • Filters
10
Category: Ball Valves
Created by: Super User

Cim 10

Fullway Ball Valve

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems, oil
pipelines, gasoline networks, saturated steam and generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure:
PN 100 (1/4" ÷ 1/2"); PN 64 (3/4" ÷ 1"); PN 50 (1"1/4); PN 40 (1"1/2 ÷ 2"); PN 25 (2"1/2 ÷ 4")
Operating temperature: -20 ÷ 150°C



12
Category: Ball Valves
Created by: Super User

Cim 12

Fullway Ball Valve

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems, oil
pipelines, gasoline networks, saturated steam and generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure:
PN 80 (1/4" ÷ 1/2"); PN 50 (3/4" ÷ 1"); PN 40 (1"1/4); PN 32 (1"1/2 ÷ 2"); PN 20 (2"1/2 ÷ 4")
Operating temperature: -20 ÷ 150°C.



14
Category: Ball Valves
Created by: Super User

Cim 14

Fullway Ball Valve

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems, oil
pipelines, gasoline networks, saturated steam and generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure:
PN 80 (1/4" ÷ 3/8"); PN 60 (1/2"); PN 45 (3/4" ÷ 1"); PN 35 (1"1/4); PN 32 (1"1/2); PN 30 (2"); PN16 (2"1/2 ÷ 4")
Operating temperature: -20 ÷ 150°C



Cim-16-316-NPT
Category: Ball Valves
Created by: Super User

Cim 16-316 NPT

Full Bore Ball Valve

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems, oil
pipelines, gasoline networks, saturated steam and generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure:
PN 80 (1/4" ÷ 1/2"); PN 50 (3/4" ÷ 1"); PN 40 (1"1/4); PN 32 (1"1/2 ÷ 2")
Operating temperature: -20 ÷ 150°C





















301-16 BL- NPT
Category: Ball Valves
Created by: Super User

Cim 301-16 NPT – 301-16 BL

Full Bore Ball Valve M/F

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems, oil
pipelines, gasoline networks, saturated steam and generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure:
PN 80 (1/4" ÷ 1/2"); PN 50 (3/4" ÷ 1"); PN 40 (1"1/4); PN 32 (1"1/2 ÷ 2")
Operating temperature: -20 ÷ 150°C







Cim-RED-5-6_1MF
Category: Ball Valves
Created by: Super User

Cim Red 5-6/1MF

Full Bore Ball Valve M/F



This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems, oil
pipelines, gasoline networks, saturated steam and generally with any non corrosive liquid.

It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure:
PN 50 (1/2"); PN 40 (3/4" ÷ 1")
Operating temperature: -20 ÷ 150°C









Cim-011-012-015
Category: Ball Valves
Created by: Super User

Cim 011- 012- 015

Mini Ball Valve

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems and
generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure: PN 150
Operating temperature: -20 to 95°C.













Cim-34-34
Category: Ball Valves
Created by: Super User

Cim 34-34/1

Rubistar – Ball Bib Cock / Antifrost



This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in water systems, for industrial and agricultural applications and generally with any non corrosive liquid.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure: PN 16
Operating temperature: -15 to 90°C













Cim-46-F-46
Category: Ball Valves
Created by: Super User

Cim 46 F-46

Right Angle Ball Valve (M/Compression) With Strainer – PN 16

Cim 46 F was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in a wide variety of sectors: heating, air conditioning, water, sanitary systems, pneumatic systems and
generally with any non corrosive liquid.

Cim 46 can be used in water and sanitary systems.

It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure: PN 16
Operating temperature: -20 to 90°C













Cim-45-39-L
Category: Ball Valves
Created by: Super User

Cim 45 - 39L

Right Angle Ball Valve – PN 16

Right Angle Ball Valve for Washing Machines – PN 16

This article was made in compliance with the quality management requirements of standard ISO 9001:2008.
All articles are tested according to the standard EN 12266-1:2003.
It can be used in water and sanitary systems.
It is guaranteed for 5 years.
It is made of a brass alloy that complies with standard EN 12165-CW617N-M.

Nominal Pressure: PN 16
Operating temperature: -15 to 90°C.
